Standard Piston Ring Styles

AD Piston Ring offers a variety of standard piston ring styles, each designed for specific applications such as combustion engines, compressors, and hydraulic cylinders. These rings are engineered for efficiency and durability.

1. Compression Ring

  • Type: One-piece, turned face, designed for quick seating.
  • Applications: Combustion engines, compressors, pumps, and hydraulic cylinders.
  • Size Range: Up to 35 inches.

2. Two-Piece Compression Ring

  • Type: For high-pressure service with superior sealing action.
  • Applications: Air, steam, and hydraulic cylinders.
  • Size Range: Up to 35 inches.

3. Three-Piece Compression Ring

  • Type: Similar to two-piece, but with an improved sealing property due to double outer rings.
  • Applications: Air, steam, and hydraulic cylinders.
  • Size Range: Up to 35 inches.

4. Oil Wiper

  • Type: Efficient wiper ring for compressors, low-speed engines, and more.
  • Applications: Drains oil below the oil ring groove.
  • Size Range:Up to 35 inches.

5. Motor Seal

  • Type: Ventilated oil control ring, designed to drain oil through the ring's face and back of the groove.
  • Applications: Combustion engines, compressors, and similar machinery.
  • Size Range:Up to 35 inches.

6. Super-Diesel Ring

  • Type: A combination ventilated scraper ring, designed to drain oil through and below the oil ring groove.
  • Applications: Combustion engines, compressors, and more.
  • Size Range:Up to 35 inches.

Applications:

These standard piston rings are ideal for use in combustion engines, compressors, pumps, hydraulic and pneumatic cylinders, and other high-pressure systems.

Availability:

  • Available in various sizes, up to 35 inches in diameter.
